GSB-250 conveyor belt sample punching machine

overview:

It is used for industrial cutting rubber,soft plastic sheet,leather,cotton textiles,cardboard and other similar materials by knife mould.

Characteristics:

1.The main cutting force:100KN,120KN,160KN,200KN,250KN.That will meet customers’ different production requirements.

2.With automatic lubrication system to reduce wear and prolong using life.

3.Electronic delay circuit is used to control the stroke lower limit position.Its high precision can improve roduct quality.Using the hand wheel height to adjust the distance between  arm and the table,which is simple,reliable and convenient.

4.Column,arm,piston rods are made of high quality steel,which are durable.

5.Inertia of the flywheel can be instantaneous cutting to reduce energy consumption.

Technical data:

Maximum cutting force
250KN
Stroke adjustment range
5-75mm
Stroke speed
0.1m/s
Distance between playing board and countertops
65-150mm
Motor power
1.5kw
 Countertops
500*1000mm
Arm size
350*550mm
Outer size
1000*900*1380mm
Host machinery weight
1050kg
