SC-2 Conveyor belt Transverse Flexibility and Trough Belt Tester

overview :

The machinery is the belt sagging under way in the free lateral flexibility and trough test equipment.It adopts PC and Siemens PLC to control ,which has the function of automatic vertical tracking and automated read-out 、 save and print the data、reporting function.This equipment up to standard of GB/T7983/ISO0703。

Constitute:

1.Rack 2.Ball screw、linear guideway、automatic tracking device  3.Platform up/down device 4.Trough height measuring device 5.PC and printer 6.Electric control

Technical data:

Maximum sample specification
200L*2600W*30Hmm
Maximum groove vertical
1250mm
Groove vertical height accuracy
(±1mm
Maximum Platform move distance
1400mm
Power voltage
AC240V   50HZ
Maximum consumed power
420W
Overall dimensions
3300X2250X540(mm)
Weight
260Kg
