Project Description
SJPR-01A conveyor belt alcohol burner combustion performance testing machine
Introduction :
SJPR-01A-type conveyor belt alcohol burner combustion performance testing machine , suitable for research institutes and factories under laboratory conditions, do all types of flame, burning test and flame retardant conveyor evaluation analysis, product line with GB / T3685-1996”Conveyor belts-Flame retardation-Specifications and test method”. Capable of detecting various types of fire-retardant conveyor belt and in full compliance with MT668-2008, MT914-2008, MT830-2008 and other national or industry standards for test test flame retardant, flame retardant product requirements.
Structure：
Alcohol torch,mobile assembly, sample holder, alcohol bottles and flow, temperature detection,electrical components
Technical data：
Power voltage | AC220V 50HZ |
Consumed power | 100W |
Flame high | 150-180（mm） |
Flame temperature | 960℃±60℃（IN 6sec fusingΦ0.71mm naked copper ） |
Reagent | 95%ethyl alcohol and5%（V/V）mix methyl alcohol |
Overall dimensions | 1470（H）*663（W）*613（T）mm |
Inner size | 1070（H）*660（W）*610（T）mm |
Weight | 70kg |
